A Guide to Submersible Pump Accessories and Enhancements

Submersible pumps truly are the unsung heroes in countless commercial water management systems across the UK. Working unseen beneath the surface, they diligently perform critical tasks like drainage, wastewater removal, water supply boosting, and circulation. However, even the best submersible pump rarely works in isolation. To unlock its full potential, ensure maximum reliability, boost efficiency, and simplify operation, a carefully selected suite of submersible pump accessories and enhancements is often essential. These additional components transform a standalone pump into a fully functional, optimised, and protected system. Whether you're installing a new system or looking to improve an existing one, understanding the available accessories for pumps is key. This guide will explore the vital supporting cast that helps your submersible pump deliver peak performance, day in and day out.

Understanding Submersible Pump Accessories: The Supporting Cast

So, what exactly falls under the umbrella of submersible pump accessories and enhancements? In simple terms, these are any components, devices, or technologies used in conjunction with the pump itself to complete the system, improve its function, protect it from damage, control its operation, or make it easier to install and maintain. Think of the pump as the engine; the accessories are the transmission, steering, brakes, and dashboard that allow the engine to do its job effectively and safely within the vehicle of your water management system. These components can be broadly categorised:

Hydraulic Accessories: Items that directly handle the water flow, connecting the pump to the wider system (e.g., hoses, pipes, valves).
Electrical Accessories: Components related to power supply and electrical safety (e.g., cables, connectors, junction boxes).
Control Accessories: Devices that automate or manage the pump's operation (e.g., float switches, control panels, sensors).
Protective Accessories: Items designed to prevent damage to the pump from debris, dry running, or electrical faults (e.g., strainers, overload relays, specific control functions).
Installation & Maintenance Aids: Components that simplify the process of installing, removing, and servicing the pump (e.g., guide rails, lifting chains).

Choosing the right combination of these accessories for pumps is crucial for building a robust, efficient, and long-lasting submersible pumping system tailored to your specific commercial needs.

Essential Accessories for Submersible Pumps: Building a Reliable System

While the specific requirements vary by application, several core submersible pump accessories are fundamental for most installations:

Discharge Hoses and Pipework

Once the pump moves the water, it needs to go somewhere! Discharge hoses or permanent pipework are responsible for conveying the fluid away from the pump to the desired outlet point.

Material Matters: Options range from flexible layflat hoses (PVC, rubber - good for temporary or portable setups) to rigid pipework (PVC, ABS, HDPE, steel, copper - for permanent installations). Material choice depends on pressure requirements, fluid compatibility, environmental conditions (e.g., UV exposure), and budget.
Diameter is Crucial: Selecting the correct hose or pipe diameter is critical for efficiency. Too narrow, and friction losses skyrocket, reducing flow rate and making the pump work harder (wasting energy). Too large might be unnecessarily expensive and may affect flow velocity. Manufacturer recommendations and flow rate calculations are key.
Length and Elevation: Remember that total discharge length and any vertical lift (elevation change) contribute to the system's head pressure, which the pump must overcome. Factor this in when selecting both the pump and the discharge line size.
Secure Connections: Reliable couplings and fittings are essential to prevent leaks. Common types include Camlock, Bauer, or Storz couplings (often for temporary hoses) and threaded or flanged connections for permanent pipework. Ensure compatibility and proper sealing. While we specialise in pumps and boilers, you can enquire about sourcing suitable hoses via our Contact page.

Float Switches for Automatic Operation

For applications like sump drainage or tank level control, manual operation is often impractical or risky. Float switches provide simple, reliable automation.

How They Work: A buoyant float containing a switch mechanism rises and falls with the water level. At predetermined levels, it triggers the switch, turning the pump on or off. Most modern switches use reliable, mercury-free mechanisms.
Types:
- Tethered/Pendulum: A common, cost-effective type where the float hangs on its cable and pivots upwards. Requires sufficient space to swing freely.
- Vertical: Uses a float moving up and down a fixed rod. Ideal for narrower sump pits where space is limited.
- Tube/Diaphragm: Less common for basic control, sometimes used for specific level sensing.
Configuration: Systems can use a single float for basic on/off control, or multiple floats for separate start, stop, and high/low alarm levels, often integrated into a control panel.
Benefits: Prevents pumps from running dry (which can cause rapid damage) and stops overflows by activating the pump automatically when needed. Provides true "set-it-and-forget-it" convenience and reliability for many Submersible Pumps applications.

Check Valves (Non-Return Valves)

An essential component in most discharge lines, a check valve acts as a one-way gate for water flow.

Function: It allows water to flow out of the pump but automatically closes to prevent water from flowing back down the pipe into the sump or tank when the pump stops.
Why It's Needed: Prevents the energy waste of re-pumping water that has just been lifted. Protects the pump from potential backspin and hydraulic shock (water hammer) that can occur as the water column reverses. Ensures the sump is effectively emptied.
Types: Common designs include swing check valves (a hinged disc swings open/closed) and spring-loaded valves (a spring holds a disc or ball closed until pump pressure opens it). Spring-loaded types can often be installed in any orientation.
Selection: Choose based on pipe size, pressure rating, and material compatibility (PVC, brass, cast iron, stainless steel). Consider "full-flow" designs to minimise pressure loss. You can find suitable options in our Pump Valves section.

Electrical Cables, Connectors, and Safety

Safe and reliable power delivery is non-negotiable for submersible pumps.

Submersible Cable: Pumps come with a certain length of specially designed waterproof power cable (e.g., H07RN-F type). It must be resistant to water ingress, abrasion, and potentially chemicals. Ensure the supplied length is adequate; avoid unnecessary joins underwater if possible.
Cable Sizing: The cable's conductor size (cross-sectional area) must be sufficient for the pump's current draw and the total cable length to prevent excessive voltage drop, which can impair performance and overheat the motor.
Connectors and Junction Boxes: If cable extension is unavoidable, use appropriately rated waterproof connectors or above-ground waterproof junction boxes. All electrical work, especially involving mains voltage and water, must be carried out by a qualified electrician according to UK wiring regulations (BS 7671).
Cable Protection: Protect cables from physical damage during installation and operation, especially where they exit the sump or run across floors.

Pump Control Panels

Beyond simple float switches, dedicated control panels offer enhanced protection, control, and monitoring capabilities, especially for larger or three-phase pumps.

Core Functions:
- Motor Starting: Direct-On-Line (DOL) for smaller motors, or Star-Delta / Soft Starters for larger motors to reduce high starting currents. VSDs also provide controlled starting.
- Overload Protection: Monitors motor current and trips if it exceeds safe levels, protecting the motor from burnout due to jamming or overload.
- Phase Protection (3-Phase): Detects phase loss, incorrect sequence, or imbalance, protecting three-phase motors from damage.
- Dry-Run Protection: Can integrate signals from float switches, conductivity probes (see enhancements), or monitor motor load to stop the pump if water level drops too low.
Additional Features: Hours run meters, status indicator lights (power on, pump running, fault), alarm outputs (for connection to BMS, sirens, beacons), automatic alternation for dual pump systems (ensuring even wear). Explore bespoke panel solutions by Contacting Us.

Protective Strainers, Grates, and Covers

Preventing debris from entering the pump is vital for longevity and performance.

Intake Strainers: Most Submersible Pumps have built-in strainers or screens at the water inlet. Ensure the hole size is appropriate for the pump's solids handling capability and the likely debris.
External Screens/Grates: In environments with heavy debris (leaves, twigs, rags), additional external screens or sump grates might be needed to pre-filter the water reaching the pump.
Pump Covers: While the pump is designed to be submerged, covers for the sump pit itself can prevent larger debris from falling in and provide a safety barrier.

Enhancements for Optimised Performance and Control

Beyond the essentials, several advanced submersible pump accessories and technological enhancements can significantly boost efficiency, controllability, and insight into your system's operation.

Variable Speed Drives (VSDs)

A transformative technology for many pumping applications.

Energy Savings: By adjusting motor speed to precisely match demand, VSDs drastically cut energy consumption compared to fixed-speed pumps, especially where flow requirements fluctuate (as per the Affinity Laws).
Process Control: Allows for precise control of flow rates or maintenance of constant pressure or water level.
Reduced Wear: Soft starting and stopping reduces mechanical and electrical stress on the entire system.
Integration: Often housed within a control panel or sometimes integrated directly into the pump/motor unit by manufacturers like Grundfos and Wilo. Requires compatible motors.

Smart Control Systems and Telemetry

Taking control panels to the next level.

Advanced Monitoring: Real-time tracking of operational parameters (current, voltage, power consumption, flow, pressure, run hours).
Remote Access: Monitor status, receive alerts (e.g., via SMS or email), and potentially adjust settings remotely via web interfaces or dedicated apps.
Data Logging: Historical performance data aids troubleshooting and optimisation.
Predictive Maintenance: Algorithms can analyse trends to predict potential failures before they happen.
BMS/SCADA Integration: Seamless communication with building management or industrial control systems using standard protocols (Modbus, BACnet, etc.).

Energy-Efficient Motors (as an Enhancement)

While often part of a new pump purchase, upgrading an existing pump motor (where feasible and economical) to a higher efficiency class (IE3, IE4, IE5) or an ECM/PMM type can be a significant enhancement, reducing running costs.

Specialised Dry-Run Protection Devices

Offering more sophisticated protection than basic float switches.

Conductivity Probes: Use low voltage across probes positioned at different levels. When water drops below a probe, the circuit breaks, signalling the control panel to stop the pump. Requires conductive liquid.
Current Monitoring Relays: Detect the significant drop in motor current (load) that occurs when a pump starts running dry, triggering a shutdown.
Pressure Switches: Installed on the discharge side, they can detect a loss of prime or pressure indicative of dry running.

Guide Rail Systems

Essential for safely and easily managing larger pumps in deep or inaccessible wet wells.

Function: Allows the pump to be accurately lowered onto, and sealed against, a fixed discharge connection point (pedestal elbow) at the bottom of the well, guided by rails mounted on the well wall. The pump can be easily lifted out for maintenance via a lifting chain without personnel needing to enter the confined (and potentially hazardous) space.
Components: Guide rails, sliding pump bracket (claw), base pedestal/discharge elbow, upper guide rail bracket. Materials are typically cast iron or stainless steel. A key safety and maintenance enhancement for relevant Submersible Pumps.

Lifting Chains and Shackles

A simple but vital accessory for installing and removing any submersible pump that's too heavy to lift manually. Use appropriately rated chains and shackles, preferably stainless steel for corrosion resistance in wet environments. Never lift the pump by its power cable.

Installation and Maintenance: Focus on the Accessories

Maximising the benefit of your submersible pump accessories requires correct installation and ongoing care, just like the pump itself.

Proper Installation of Accessories

Control Panels: Mount securely in a dry, accessible location. Ensure correct wiring by a qualified electrician.
Float Switches: Position carefully to ensure correct activation levels and guarantee free, unobstructed movement away from pump inlets or sharp edges.
Check Valves: Install in the correct orientation (flow direction arrow) and ensure valve mechanism moves freely.
Hoses/Pipes: Ensure all connections are watertight and pipework is adequately supported.
Guide Rails: Must be installed perfectly plumb (vertical) and parallel for smooth pump travel.

Routine Maintenance of Accessories

Float Switches: Periodically clean the float and check its movement. Manually test its operation.
Check Valves: Listen for proper closing (a gentle 'thud' is often normal). Periodically inspect internal components if possible, especially in systems prone to debris.
Control Panels: Keep clean and dry. Regularly check terminal tightness (by qualified personnel). Test overload settings and alarm functions periodically.
Hoses/Couplings: Inspect for leaks, abrasion, kinks, or UV damage.
Strainers/Filters: Clean regularly as part of pump maintenance.

Monitoring Accessory Performance

Use the features of your control system (indicator lights, alarms, logged data) to monitor not just the pump, but the correct functioning of crucial accessories like float switches and overload protectors.

Success Stories: The Impact of the Right Accessories

Real-world scenarios highlight how crucial accessories for pumps can be:

Preventing Dry-Run Disaster: A commercial property frequently experienced costly motor burnouts on their basement sump pump due to the pump occasionally running dry when the float switch jammed. Installing a control panel with integrated motor load monitoring for dry-run protection completely eliminated the problem, saving them significant repair costs and downtime.
Simplifying Maintenance: A facility with deep wastewater sumps struggled with hazardous and time-consuming pump removal for maintenance. Retrofitting guide rail systems allowed maintenance staff to lift and service the large Submersible Pumps quickly and safely from the surface, drastically reducing maintenance time and improving worker safety.
Achieving Energy Savings: An office building identified their fixed-speed water booster pumps as major energy consumers. By installing VSDs controlled by pressure transducers – key accessories for pumps in this context – they were able to maintain constant building water pressure while cutting pump energy consumption by over 40%, providing rapid payback on the enhancement.

National Pumps and Boilers: Your Source for Pump Accessories

At National Pumps and Boilers, we understand that a successful pumping system relies on more than just the pump. We offer a wide range of essential submersible pump accessories and enhancements, backed by expert advice.

Comprehensive Selection: From Pump Valves and control panels to float switches and more, we can help you source the components you need.
Expert Guidance: Our knowledgeable team can advise on the compatibility and selection of accessories for various pump brands (like Grundfos, Lowara, Wilo) and applications.
Quality Assurance: We supply high-quality accessories designed for reliability and performance in demanding commercial environments.

Ready to Enhance Your Submersible Pump System?

Don't overlook the vital role of accessories and enhancements in your water management strategy. Optimising your system with the right components can lead to improved reliability, increased efficiency, lower running costs, and greater peace of mind.

If you're looking to upgrade your existing setup, install a new system, or simply need advice on the best submersible pump accessories for your specific challenges, contact National Pumps and Boilers today. Let's work together to ensure your submersible pump system is fully equipped to perform at its best.
